GETABEC KESSEL

  • Design :3-pass wet back Fire Tube Steam Boiler

  • Capacity :1, 000 to 30, 000 kg/hr

  • Pressure :Up to 24 barg

  • Type of fuel : Light Oil, Heavy Oil, Gas

  • Design :3-pass wet back Fire Tube Steam Boiler

  • Capacity :1, 000 to 30, 000 kg/hr

  • Pressure :Up to 24 barg

  • Type of fuel : Light Oil, Heavy Oil, Gas

GETABEC KESSEL  that we produce is a high-efficiency steam and hot water boiler for every application, in various designs with energy saving system and fully automatic operation without need to constant supervision. These boilers are three pass, wet-back design principle. The water contents can be quickly transformed into steam. Our boilers always have sufficient steam reserve, even during sudden peak demand period.

Using a gas or oil or dual fuel burner, the frame intensity is matched virtually instantly to the steam or hot water consumption, taking into account the fuel characteristic. By the way, another positive factor is that a large flame tube effectively reduces the NOx emission.

GETABEC KESSEL  can cope easily with peak and low-demand periods for steam or hot water. Output per boiler up to 30 ton/hr. Operating pressure up to 24 bar.  GETABEC KESSEL  can produce saturated steam, low-pressure saturated steam, superheated steam and high pressure hot water as required by local heat, district heat and process heat, from the individual boiler to large boiler plant, boiler with feed water treatment, feed water storage and deaeration, with heat recovery assemblies, with noise suppression, with special components.

Upon request, we can also show you operation reference installations.

All parts of boiler from are sturdily built, with plenty of reserve performance. Only components internationally recognized brand named are used, with pressure controller and safety pressure limiter, equipped for fully automatic boiler operation. We trust in our service teams by our qualified engineers and technicians complete customers requirements as well as parts availability.
